EF3L15

Low Cost, Low Power

Product Brief

EF3L15 series FPGA products launched by Anlogic Infotech are positioned in the low-cost and low-power FPGA market. EF3L15 devices are intended for high-volume, cost-sensitive applications, enabling system designers to reduce costs while meeting growing bandwidth requirements. EF3L15 devices are based on the optimized low-power technology and deliver high functionality at the lowest cost.


Product Table

Find 3 Results
Device DFFs LUTs DistributeRAM eRAM-9K eRAM-Total M18*18 PLL USER IO USER FLASH Package Methods Package Size
EF3L15CG256 1520 1520 12K 12 108K 8 1 207 4Mb caBGA256 14*14
EF3L25CG256 2520 2520 20K 12 108K 8 1 207 4Mb caBGA256 14*14
EF3L45CG256 4480 4480 35K 12 108K 15 1 207 4Mb caBGA256 14*14
  • Product Features
  • Application Scenarios
  • Materials Download

Product Features

  • Flexible logical structure

    1520-4800 LUTs, supporting up to 207 user IOs

  • Built-in flash

    Built-in 4Mb flash, no external device required, supporting fast power-up

  • High-performance Flexible Input/Output Buffer

    Compatible with 5V input and supporting hot-swapping

  • Enhanced security design

    Each chip has a unique 64-bit DNA
