MIPI Video Splicing

release time2022-07-14

System description: Input video with two cameras and 1 MIPI CSI, use EF2 device for video splicing, and output the video to CPU via one MIPI CSI.

System requirements:

    (1) A total of 7 pairs of MIPI IOs with two MIPIs for input and one MIPI for output.

    (2) Up to 3 I2Cs are required for Sensor configuration, totaling 6 IOs.

    (3) Internal memory is required for more flexible image stitching and conversion.

IP requirements:

    (1) CSI-2 RX , CSI-2 TX

    (2) I2C Master, I2C Slave





Recommended for FPGA
